Company News

GSOLA Sun Simulator Performs Excellent

In “Proficiency Testing on the electrical performance of bi-facial PV modules”

SERIS (Solar Energy Research Institute of Singapore ) organized Proficiency Testing on Bi-Facial Solar Module IV properties, which started from Jan 2018, tier 1 labs from 13 countries and regions took participate in this inter-comparison, such as NREL, JRC, AIST, Fraunhofer and etc.

In Apr of 2020, SERIS issued the final report. The testing data from Gsola lab is same with international tier 1 labs, it proves that China made solar simulator meets the international standards and has same performance with solar simulator in tier 1 labs.

The test was performed strictly according to IEC60904-1-2. It required all participants test main IV parameters of mono-facial and bi-facial module samples at different conditions, including short –circuit current (Isc), open-circuit Voltage (Voc), front Power (Pmax,f), rear Power(Pmax,r), total max power (Pmax), Bifaciality and etc……

In the test, results from the world's top laboratories were used as reference and were compared with other participants. Evaluation of performance was based on the calculation of Z score and En score. The Score shall be Good, Satisfactory, Questionable or Unsatisfactory.

GSOLA values the inter-comparison. From beginning, GSOLA cooperated with NIM (National Institute of Metrology) closely, took Measurement Uncertainty into account, bought 2 kinds of high precision reference solar cells, and corrected spectrum mis-match……. Gsola flasher is scored as Good for all samples testing, including 2 pcs mono-facial modules and 3 pcs bi-facial modules.

“GSOLA always values products quality, they invite third authority to calculate all of new products to ensure good stability and high precision, they deserve to get such good result in this inter-comparison” said by Professor Xiong from NIM.

The test verifies the testing capability of authoritative laboratories across the world, which helps to improve testing stability and accuracy, promote technical exchanges and discussions among international laboratories, and guide PV industry to development with higher quality.

Test Report

2 pcs mono-facial module（Good）

3 pcs bi-facial modules（Good）

3 pcs bi-facial modules（Good）

3 pcs bi-facial modules（Good）

BackGround

Because of Bi-facial solar module development, SERIS organized the Proficiency Testing. It started from Jan in 2018, famous research institutions and laboratories from 13 countries and regions took participate in, such as NREL , JRC, AIST, Fraunhofer and so on…….

Last Tuesday, United Nations Industrial Development Organization International Solar Energy Center For Technology Promotion & Transfer（UNIDO） organized over 40 officials from 21 countries, like Grenada, Cuba, Djibouti, Panama, Pakistan, Ethiopia, Cambodia, Ghana, Cameroon and other countries, to visit Gsolar Power Co.,Ltd - the leading solar industry equipment manufacturing enterprise.

Mr. Huang (GM), warmly welcomed national officials. They exchanged opinions about China PV market trends and potential cooperation with each other. Both sides communicated in strengthening the cooperation and promoting the solar industry worldwide.

Company leaders introduced our history, honors, achievements to our new friends and showed guests around our workshop. The officials showed great interests and satisfied in our new equipment.

Two new launched devices are XJCM-11 and GEL-M10.

XJCM-11 is a sophisticated sun simulator. The new generation solar simulator (model: XJCM-11) performed at A+A+A+ level in non-uniformity of irradiance, spectral match and temporal instability of irradiance. The testing features are twice better than international standard (IEC 60904-9).

- Wider spectrum: Spectrum range is extended from 400-1100nm to 300-1200nm, this improvement solves 300-400nm spectrum missing problem, which could make the testing result of high-efficiency solar cells and modules more accurate.

- Longer pulse duration: Pulse duration was extended from 10ms to 200ms, and it’s adjustable. Longer pulse duration make it possible to effect accurate testing to PERC, HIT, IBC and other modules with higher efficiency.

- GEL-M10 is our latest EL deficiency detector which applies one camera with 24million pixels by three shots. Its good testing result makes it a star product in china.

- More than 42 million effective pixels, Germany customized lens, guarantee the picture quality.

- Customized optical filters (no dark room needed).

- More than 11 kinds of picture software processing functions and 4K display screen. Provide you an ever clearest picture.

- The equipment has the certificate of Institute of Metrology, its measurement result ≤0.3 mm/lp, which is currently the best resolution.

After this visit, United Nations delegation highly praised the development of Gsolar and positively emphasized that there’s large room to cooperate with each other. We hope Gsolar will do better in solar equipment manufacturing and help with solar industry in the future.

Gsolar firstly launch ‘Three In One’ solar simulator around the world (A+A+A+/full spectrum/long pulse)

Gsolar Power Co., Ltd (hereafter referred to as Gsolar) will show the 11th generation of unthinkable product - A+A+A+/full spectrum/long pulse solar simulator(model :XJCM -11A ), during SNEC expo (2016) in shanghai.

It is reported that this top test equipment, integrated three of the world's leading indexes:

• 1. A+A+A+ performance. Non-uniformity of irradiance, Spectral match, Temporal instability of irradiance, these three core performance indexes are twice better than highest international standard (IEC 60904-9).
• 2. Full spectrum. Spectrum range is extended from 400-1100nm to 300-1200nm, so this solves 300-400nm spectrum lost problems existed among most of solar simulators on the market. Full spectrum accomplishes Improve testing accuracy effectively of high-efficiency solar cell.
• 3. Long pulse. Testing pulse width can be extended from 10ms to 150ms, even 200ms. This makes it meet requirements for testing PERC, HIT, IBC and other new technology solar cells and solve the test deviation caused by large capacitance effect.

Gsolar takes orders to the sprits – EXCELLENCE、INNOVATION、ENDLESS and SATISFACTION and constantly updates product technology.Gsolar is the only PV equipment supplier in china.the equipment of IV series obtained CE certificate in 2008 and TUV certificate in 2009,then gained TaiWan ITRI AAA certificate. The equipment of EL series obtained TUV certificate and patent certificate. owning top one market share and export machines to Germany、Spain、France、Japan、American and etc.

Gsoalr Adheres to the concept of continuous improvement to producing machines and providing services the customers satisfied with.

Gsolar solar module tester won the award “PV industry outstanding innovative technical application in 2015”

On 15th January 2016, Gsolar’s innovative application, Full Spectrum solar simulator (shell reflecting model), won the award “PV industry outstanding innovative technical application in 2015”. This award is for commending the attribution to the PV industry and spreading the latest Technological achievements, chosen by “PV industry observation”. Gsolar is running ahead among related PV equipment manufacturing companies, highly rated by experts in this field.

Full Spectrum solar simulator (shell reflecting model) model faces down, using xenon to simulate the sun light for testing. Three core performance indexes fit the A+A+A+ standard, and are all twice better than the highest international standard (IEC 60904-92007). The improved structure of equipment makes spectrum range extend to 300-1200nm, which could also be 1700nm and even wider. The new XJCM-10A+ can test most kinds of silicon solar cells. High accuracy infrared thermometer and four-wire configuration connected solar module make test results more accuracy. It’s convenient to use, each testing time is less than 1 second and test interval could be less than 10 seconds. The prospect of it is promising and the equipment performance gains the recognition of a lot of experts.

The project leader said: the application of full spectrum solar simulator break the monopolization in this field and provide the necessary reference for PV equipment especially solar test equipment domestic production level. Besides, this will increase productivity and decrease the production costs markedly.

This new testing technique reduces testing costs sharply, it could also help cut the module generating costs. In addition, lots of solar module manufacturers have already put it into operation and this attracts more and more companies’ attention overseas. The testing results show the excellent stability, accuracy, more importantly, the maintenance cost is lower than before, so that would be a wise choice to use this XJCN-10A+ to replace the outdated or expensive equipment.

Gsolar high-end automatic assembly line running successfully in India

It is reported that Gsolar Power Co.,Ltd (hereinafter referred to as "Gsolar") exports 75MW high-class automatic module line to India. After quick installation, debugging and stable running in one month, the whole module line has recently successfully passed acceptance inspection. In the process of debugging and running, Gsolar won clients highly recognition and praise with superior equipment performance and good service. The line enable Gsolar become Chinese manufacturer which export the turn-key line to India, once again proved the Gsolar have strong technical strength and good after-sales service.

According to the project leader of Gsolar introduction, this auto module line successfully won the best quality module manufacturer in Indian. The each unit of the whole line can be the perfect combination, are closely connected, the quality refer to European standards, to achieve the automatic feeding, the whole line adopt steel structure and metal plate, attractive appearance, all pipelines are in the chain inside, the electrical part mainly use world famous brand components. The assembly line is stable, high efficiency, reliable performance, easy maintenance, all touch screen operation, and online monitoring design. Project leader also said that Gsolar team gave customers deep impression by their efficiency and professionalism.

With the solar industry technology improving, cell efficiency test method also tends to be more precise, currently on the market ordinary spectrometers have been unable to meet the spectrum compatibility testing, Gsolar and the most authoritative Academy of Sciences in China have proved that only the spectrometer models for S1506053U can be met spectral compatibility test. Gsolar remind our customers must note the spectrometer model when doing equipment measurement to ensure accurate spectral matching.

Gsolar Power Co., Ltd was awarded "2015 Annual Excellent Component Upstream Supplier" with the test equipment (solar simulator, EL detector) in 2015 "Solar Cup" PV industry awards ceremony on 5th Nov.

The "Solar Cup" PV industry activities held by national solar PV product quality supervision and inspection center, Wuxi new energy chamber of commerce, and Solarbe Sorby PV network, to set up the industry benchmark and promote development as the goal, overall focus, summarize the innovative technology, products and new business model of the whole industry.

Gsolar founded in 2006, on the development of the "good faith management, leading technology, cooperation and win-win" business principle, we have hundreds of clients, own more than 60% market share.

According to “China PV industry association constitution”, Gsolar Power Co., Ltd is officially admitted association member unit and awarded the certificate by China PV industry association.

Recently, the international authoritative laboratory (SGS CSTC Standards Technical Services Co., LTD) successfully purchase new type sun simulator GIV-2A of Gsolar as their testing equipment. As the world's leading and national authoritative laboratory, SGS select the equipment of Gsolar in many domestic and foreign manufacturers , proving again that the equipment of Gsolar has been reached the world advanced level.

SGS is a global leader in inspection, verification, testing and certification organization, is recognized as the benchmark in quality and integrity. SGS is a global leader in inspection, verification, testing and certification organization, is recognized as the benchmark in quality and integrity.

It is reported that new type sun simulator GIV-2A of Gsolar, internal orientation for the A+A+A+ standard, the indicators are 2 times higher than the highest international standards (IEC60904-9). Test area expanded from the original 2000 X 1100mm to 2000 X 2000mm, convenient for large-area components and double glass component testing. Spectral mismatch narrowed from 25% to within 10%, ensure component receives light and sunlight closer. Irradiance unevenness from the original A-class 2% reduced to within 1%, greatly improve the stability of the test and narrowing differences between devices. Irradiance instability reduced from the original A-class 2% to less than 1%, the actual measurement result was 0.06%. Spectral range from the original 400-1100nm extended to 300-1100nm, solve the sun simulators on the market 300-400 nm band spectral problem.

India’s best quality module manufacturer HHV resolutely decided to select Gsolar all-steel high-end whole solar module assembly line after comprehensive consideration. More than 40 experts in the industry visited and inspected the assembly line and gave a high degree of praise. The whole solar module assembly line was shipped on 3rd August.

It is reported that the whole solar module assembly line which Gsolar sent to India are self-developed design, each unit can be perfect combination and closely connected. The electrical parts mainly adopt imported components, the assembly line smooth transmission, high efficiency, reliable performance, easy maintenance, aesthetic appearance, multi-standard module production across touch- screen operation, inline monitoring of production humanized design. The core equipment used IV + EL tester, the new inline EL detector, 24 layers stacker, automatic framing machine with overflowing glue etc.

IV + EL tester has two completely different types of test functions meanwhile to meet the electrical property of the solar module and EL defect detection requirements. This equipment can save space, save manpower and material resources, improve production test efficiency.

IV+EL Tester

New inline GEL-M6 EL detector has broken the traditional uncover and close-lid type test procedures, no air, no darkroom, using a new power supply and German custom lens. Used for assembly line, the auto guide rail direction is optional. With up to 11 kinds of image processing software, including brightness adjustment, enlarged, cropped, pseudo-color, rotation and so on. Ensure the quality of the picture.

New inline GEL-M6 EL detector

Stacker unit adjust the number of solar module in the production process to ensure the smooth operation of the assembly line. If downstream run unobstructed, transmit to next link through stacker table; if downstream operate busy, enhance stacker stand to store up to 24pcs solar panels.

Stacker Unit

After auto framing machine with overflowing glue complete module lamination, the aluminum alloy frame extruding positioning, and then fix the frame with servo motor. To achieve framing and aluminum alloy frame fixed on a single device, thereby simplifying the work intensity, save time, improve product quality.

Auto framing machine with overflowing glue

Indian HHV product quality has the top rank in the market, high-end auto assembly line they chose, it is to make high-quality products in the PV market. Gsolar will be continue to research and design more perfect products to better serve our customers. Gsolar will always uphold the technology as the core, good faith, based on the market. Win the trust by the quality, to continuously improve the development.

Gsolar Power Co.,Ltd will attend the 8th Solarex İstanbul 2015 held on 9th-11th April in Istanbul Expo Center. We are aimed at to seek more cooperation chance and to expand business in Turkey.

During the expo, Gsolar will show 4 international leading and novel testing machine during the expo, including IV+EL tester, A+A+A+LED solar cell tester, Inline solar module EL detector , the forth - generation solar module assembly line. We are ready to answer all your enquiries and provide you best solutions.

Recently,all of 10 solar simulators which one of Gsolar’s cutomers is using.pass the AAA test taken by TUV Rheinland, including both solar cell tester and module tester.

TUV Rheinland is famous for it's high-quality and rigorous test service and provides varieties of professional assessment equitably and independently.TUV test items involved six fields:transportation、 science、education& Consulting、management system. the certification issued by TUV Rheinland is recognized by EU.

Solar simulator test service is a new one that TUV Rheinland provides.it is done on the base of the IEC60904-9 standards strictly, Which represents the rigorous and exacting European standard.

Gsolar passes the audit taken by TUV Rheinland successfully, which shows reliable product quality and perfect enterprise management system.

TUV Rheinland is famous for it’s high-quality and rigorous test service and provides varieties of professional assessment equitably and independently.TUV test items involved six fields:transportation、science、education& Consulting、 management system. Which represents the rigorous and exacting European standards .the certification issued by TUV Rheinland is recognized by EU.

Gsolar takes orders to the sprits – EXCELLENCE、INNOVATION、ENDLESS and SATISFACTION and constantly updates product technology.Gsolar is the only PV equipment supplier in china.the equipment of IV series obtained CE certificate in 2008 and TUV certificate in 2009,then gained TaiWan ITRI AAA certificate. The equipment of EL series obtained TUV certificate and patent certificate. owning top one market share and export machines to Germany、Spain、France、Japan、American and etc.

Gsoalr Adheres to the concept of continuous improvement to producing machines and providing services the customers satisfied with.

34 Officials of the United Nations solar energy development center visit Gsolar on 28,Aug,2012.all stuffs of Gsolar receive them warmly. They visit our machines and communicate about the present situation and prospects of PV industry.

During the visit,the officials show great interests in our machines and speak highly of our advanced technology.

Solar simulator of type XJCM-9 of Gsolar obtains Taiwan ITRI AAA certification in Apr,2012. Being the PV equipment supplier in china who owns the honor until now.

ITRI is the largest industrial technology research and development institution. it once again shows excellent quality of Gsoalr’s machines according to owning the certification The machines of IV series obtain CE certificate in 2008 and TUV certificate in 2009,then that of EL series gain TUV certificate and patent certificate. Gsolar owns top one market share in china and export machines to Europe, USA, Asia etc.

Till now,Gsoalr is the only PV testing machine supplier that has TUV/CE certification and Taiwan ITRI AAA certification. Which shows that Gsolar constantly strives for technological innovation and excellence.
